List of Spectrometry Cuvettes
Updated version (24th January 2022).
There are 14 Absorption / Fluorescence Cuvettes (Spectrofotometer / Fluorometer Cells) available stored in 8 plastic boxes (see photo below the table).
| No. | Use | Material type | Wavelenghts Min [nm] | Wavelenghts Max [nm] | Volume [ul] | Manuf. | Code | Box | Location | Photo | Comments |
| 1 | Fluorescent | Quartz | 170 | 2700 | 50 | Starna | 6Q | F1 | Radek Office |  |
Z-Dimension of side window is 8.5mm |
| 2 | Fluorescent | Quartz | 360 | 2000 | 3500 | noname | 8G | F2 | B32 UV-VIS |  |
|
| 3 | Fluorescent | Quartz | 360 | 2000 | 3500 | noname | 8G | F2 | B32 UV-VIS | |
|
| 4 | Fluorescent | Glass | 334 | 2500 | 1400 | Hellma | 12 G | F3 | B32 UV-VIS |  |
|
| 5 | Fluorescent | Glass | 320 | 2500 | 700 | Starna | 8 SOG | F3 | B32 UV-VIS | |
|
| 6 | Fluorescent | Glass | 320 | 2500 | 700 | Starna | 8 SOG | F3 | B32 UV-VIS | |
|
| 7 | Absorbtion | Glass | 320 | 2500 | 700 | Hellma | OS | A1 | B32 UV-VIS |  |
|
| 8 | Absorbtion | Glass | 320 | 2500 | 700 | Hellma | OS | A2 | B32 UV-VIS |  |
|
| 9 | Absorbtion | Glass | 360 | 2000 | 3500 | noname | - | A3 | B32 UV-VIS |  |
|
| 10 | Absorbtion | Glass | 320 | 2500 | 3500 | Hellma | OS | A3 | B32 UV-VIS | |
|
| 11 | Absorbtion | Quartz | 170 | 2700 | 700 | Starna | 6Q | A4 | B32 UV-VIS |  |
|
| 12 | Absorbtion | Quartz | 170 | 2700 | 700 | Starna | 6Q | A4 | B32 UV-VIS | |
|
| 13 | Absorbtion | Glass | 320 | 2500 | 1400 | Starna | 13SOG | A4 | B32 UV-VIS |  |
|
| 14 | Absorbtion | Glass | 320 | 2500 | 1400 | Starna | 13SOG | A4 | B32 UV-VIS | |
Old deprecated list of cells
Characterization |
FL/ABS |
No. |
Material |
Room |
Quantity |
Type |
Path Length |
Match Code |
| 2.5ML | FL | 1 | SOG | 11A | 2 | 3 | 10mm | 9 |
| Semi Micro | FL | 2 | SOG | 11A | 2 | 18-F | 10mm | 8 |
| Semi Micro | ABS | 3 | Q | 11A | 2 | 18/B | 10mm | 6 |
| 2.5ML | FL | 4 | G | 11A | 2 | 3 | 10mm | 6 |
| Semi Micro | FL | 5 | Q | 11A | 2 | 9 | 10mm | 7 |
| Semi Micro | FL | 6 | G | OP office | 1 | 9-F | 10mm | 12 |
| Flow | FL | 7 | Q | OP office | 1 | 3 | 10mm | - |
| 2.5ML | ABS | 11 | Q | OP office | 2 | 1 | 10mm | - |
| 2.5ML | FL | 9 | G | OP office | 2 | 3 | 10mm | 6 |
| 2.5ML | ABS | 10 | G | 12A | 1 | 3 | 10mm | 6 |
| 2.5ML | ABS | 8 | G | 12A | 2 | - | - | 6 |
| 2.5ML | FL | 12 | Q | RK office | 1 | 3 | 10mm | 6 |
| 2.5 | FL | 13 | SOG | RK office | 2 | 3 | 10mm | 10 |
| Semi Micro | ABS | 14 | SOG | RK office | 1 | 18/9 | 10mm | 9 |
| Semi Micro | ABS | 15 | SOG | RK office | 1 | 18/9 | 10mm | 9 |
| Sub Micro | FL | 16 | Q | RK office | 1 | 16.100-F | 10mm | 6/Z8.5 |
| Sub Micro | FL | 17 | Q | RK office | 1 | 16.100-F | 10mm | 6/Z8.5 |
| Triangular | FL | 18 | SOG | RK office | 1 | 4-SB | 10mm | 14 |
| Mirror | FL | 19 | Q | RK office | 1 | 3 | 10mm | MC |
